KV100100VS Vehicle Mounted x ray inspection system
The Krystalvision KV100100VS Mobile Scanner is specifically designed and produced to be mounted onto light truck chassis, complete with insulated operator cabins. This innovative solution enables the convenient relocation of vehicles for temporary security inspections or when additional screening is necessary. The KV100100VS model is primarily intended for thoroughly examining large luggage, cargo and packages. It boasts a spacious tunnel entrance measuring 100 mm (W) by 100 mm (H), featuring a motorized conveyor at the entry point for effortless item handling. This mobile scanner is outfitted with collapsible roller tables, an integrated CCTV surveillance system, a two-way intercom setup and reliable power backup through UPS or a power generator. Additionally, it includes a retractable awning to provide protection against sunlight and rain.
Employing cutting-edge software, the KV100100VS offers operators the ability to meticulously analyze objects using image enhancement tools, ensuring exceptional threat detection capabilities. The Krystalvision mobile scanner proves to be an invaluable asset for immediate security screenings at airports, borders, concerts, sports events, conferences and high-profile political gatherings.
Certifications
Technical Feature:
- Comfortable operator cabin with air-conditioning
- Onboard power generator backup
- Excellent image and detection capabilities
- Mobile, vehicle-based flexible screening solution
- Meets AERB standard along of food safety & film safety up to ISO1600/33DIN
- Built in self-check and diagnosis function.
- Built in self-check and diagnosis function.
Technical Specification:
- Tunnel opening: - 1000 mm (W) x 1000 mm (H)
- Steel Penetration: - Standard 35 mm, Typical 37 mm of steel
- Wire Resolution: - 40 AWG Typical, 38 AWG Guaranteed
- Tunnel opening: - 1000 mm (W) x 1000 mm (H)
- Conveyor Speed: - 0.18 m/sec to 0.3 m/sec
- Vehicle:- Integrated with BSVI complaint Indian make truck chassis
