KV100100DV Dual View X Ray Baggage Inspection System
Krystalvision KV100100DV is dual view multi energy X Ray Security Inspection system designed for scanning large objects such as registered bags, cargo, pallets up to a size of 95 cm x 95 cm. KV100100DV is equipped with two separate X- Ray generators in different beam angles, providing scanned image of vertical and horizontal view (dual view) of objects. Images from each view are shown on separate monitors. Dual view of each object is displayed to the operator simultaneously, hence shortening inspection time and accurately finding dangerous objects and contraband hidden beneath over¬lapping objects in tightly packed baggage.
KV100100DV has high throughput with conveyor speed 0.3 m/sec and has superior detection tech-nology and unmatched discrimination features. KV100100DV is designed to meet the daily requirements of railway stations, airports, seaports, transportation infrastructure, cargo services etc.
This design is offered in combination with the optional artificial intelligence (AI) feature for automatic detection and alerts of dangerous threats and contraband objects such as knife, pistol, scissors, blades etc without any additional hardware.
Certifications
Technical Feature:
- Dual View Imaging with Superior and efficient detection capabilities
- Improved detection capabilities due to dual view technology
- Sophisticated image capture, display and archival
- Optional powered with AI feature.
- Integrated self-diagnostic reporting capability
- Power full dual x ray source technology
- Easy to integrate with AI camera
- Easy to integrate with motorized conveyor ramp
Technical Specification:
- Tunnel opening: - 1000 mm (W) x 1000 mm (H)
- Steel Penetration: - Standard 35 mm, Typical 37 mm in steel
- Wire Resolution: - 40 AWG Typical, 38 AWG Guaranteed
- Conveyor Height: - Approx 800 mm from ground
- Conveyor Speed: - 0.18 m/sec to 0.3 m/sec
- Weight: - Approx 1800 Kg
